Construction Documentation
Permit sets, construction drawings, as-builts, and redline revisions that hold up in the field.
CAD Engineer · Architectural Designer
CAD Engineer and Architectural Designer with 35+ years creating construction drawings, technical documentation, and CAD layouts—from concept through construction and field verification.
Years creating construction drawings, CAD layouts, and technical documentation
Professional roles across architecture, engineering, and prototype CAD
Permit sets, construction drawings, as-builts, and redline revisions that hold up in the field.
SolidWorks and SketchUp models, production jigs, CNC-ready components, and design validation.
Cross-discipline collaboration with structural, electrical, mechanical, and manufacturing teams.
I’m a CAD Engineer and Architectural Designer with deep experience in construction drawings, technical documentation, and CAD layouts for architectural, engineering, manufacturing, and construction projects.
Beyond drafting, I bring hands-on prototype work—creating and modifying CAD models, production jigs, and components in SolidWorks and SketchUp, interpreting engineering drawings, and recommending design improvements after validation testing.
My approach combines technical depth with constructability thinking so documentation and models move cleanly from concept through field verification.
35+
Years Experience
AutoCAD
Core Platform
3
Countries Worked
Permit sets, as-builts, and 3D perspectives — plus a walkthrough of Marian World Sanctuary in Libmanan, Camarines Sur.
Featured · 3D walkthrough
Libmanan, Camarines Sur, Philippines · 70 acres
Designed by Arnel Mario G. Paranal. The largest rosary in the world, laid out on a 70-acre lot. This Bulalakaw sequence orbits the sanctuary so you can read the full site in motion.
Architectural set · 15 sheets
Two-storey house with roof deck · Cagayan de Oro · A / E / P / S
As-built set · 7 sheets
Three-storey as-built documentation
Architectural set · 15 sheets
Floor plans A1–A14 plus structural S1
Structural set · 6 sheets
Foundation and structural sheets S2–S7
Presentation sheets of residential, commercial, and institutional massing.
35+ years across architectural design, construction documentation, engineering drafting, and prototype CAD.
Finelite Inc.
PC Design Services
C+A Architects
Arnel Mario Paranal & Associates
E&A Engineers Inc.
Sumitomo Construction
